All commands are carried out via a “TOUCH” human/machine graphic tactile interface panel where, in addition to the choice of 5 languages (Italian, German, English, French and Spanish), the following can be set:
- Reel diameter to be rewound with relative machine stop
- Choice of diameter where the pressure roller on the coil must act and then move away or remain
- Paper tension with paper width and weight input. The tension varies as the roll increases in diameter
Technical data
- Paper width: 520 mm
- Weight from 45 to 250
- Coil ø 1270 mm max
- Mechanical speed: 400 m/min
- Pneumatic coil holder shaft ø 70 mm
- Pneumatic coil loading/unloading
- Trees for assembling separating knives
- Various safety features
